BabylonJS 物理引擎

Babylon.js 具有物理引擎插件系统,有助于向场景中添加交互。它显示了 2 个对象之间的碰撞和弹跳,使其更像现实生活中的交互。演示将显示球相互碰撞和随着碰撞移动,然后休息。我们注意到类似台球游戏的行为,玩家用棍子击球,球与其他球碰撞等等。在这里,物理引擎试图给出一个真实的球撞击地面时碰撞和弹跳的视图。该引擎具有类和 API,可帮助应用应用脉冲、力、改变速度、回调函数,以便在需要时以及在网格与其他网格发生碰撞时我们需要执行某些操作时调用。
可以使用 3 个物理插件-
Cannon.js Oimo.js Energy.js

演示

<!doctype html>
<html>
   <head>
      <meta charset = "utf-8">
      <title>BabylonJs-Ball/Ground Demo</title>
      <script type = "text/javascript" src="https://cdn.babylonjs.com/Oimo.js"></script>
      <script src = "babylon.js"></script>
      <style>
         canvas {width: 100%; height: 100%;}
      </style>
   </head>
   <body>
      <canvas id = "renderCanvas"></canvas>
      <script type = "text/javascript">
         var canvas = document.getElementById("renderCanvas");
         var engine = new BABYLON.Engine(canvas, true);
         var v3 = BABYLON.Vector3;

         var createScene = function () {
            // this creates a basic Babylon Scene object (non-mesh)
            var scene = new BABYLON.Scene(engine);
            var camera = new BABYLON.ArcRotateCamera("Camera", 0.86, 1.37, 250, BABYLON.Vector3.Zero(), scene);

            camera.attachControl(canvas);
            camera.maxZ = 5000;
            camera.lowerRadiusLimit = 120;
            camera.upperRadiusLimit = 430;
            camera.lowerBetaLimit =0.75;
            camera.upperBetaLimit =1.58 ;
            new BABYLON.HemisphericLight("hemi", new BABYLON.Vector3(0, 1, 0), scene);
            var randomNumber = function (min, max) {
               if (min == max) {
                  return (min);
               }
               var random = Math.random();
               return ((random * (max-min)) + min);
            };
            var mat = new BABYLON.StandardMaterial("ground", scene);
            var t = new BABYLON.Texture("images/gr1.jpg", scene);
            t.uScale = t.vScale = 10;
            mat.diffuseTexture = t;
            mat.specularColor = BABYLON.Color3.Black();

            var g = BABYLON.Mesh.CreateBox("ground", 200, scene);

            g.position.y =-20;
            g.position.x = 0
            g.scaling.y = 0.01;
            g.material = mat;

            scene.enablePhysics(new BABYLON.Vector3(0,-10, 0), new BABYLON.OimoJSPlugin());

            g.physicsImpostor = new BABYLON.PhysicsImpostor(g, BABYLON.PhysicsImpostor.BoxImpostor, {
               mass: 0,
               restitution: 0.9
            }, scene);

            var getPosition = function(y) {
               return new v3(randomNumber(-100, 100), y, randomNumber(-100, 100));
            };

            var allspheres = [];
            var y = 50;
            var max = 50;

            for (var index = 0; index < max; index++) {
               var redSphere = BABYLON.Mesh.CreateSphere("s" + index, 32, 8, scene);
               redSphere.position = getPosition(y);
               redSphere.physicsImpostor = new BABYLON.PhysicsImpostor(redSphere, BABYLON.PhysicsImpostor.SphereImpostor,{
                  mass: 1, restitution:0.9
               }, scene);

               redSphere.physicsImpostor.applyImpulse(new BABYLON.Vector3(1, 2,-1), new BABYLON.Vector3(1, 2, 0));

               var redMat = new BABYLON.StandardMaterial("ground", scene);
               redMat.diffuseColor = new BABYLON.Color3(0.4, 0.4, 0.4);
               redMat.specularColor = new BABYLON.Color3(0.4, 0.4, 0.4);
               redMat.emissiveColor = BABYLON.Color3.Red();
               redSphere.material = redMat;

               // push all spheres in the allspheres variable
               allspheres.push(redSphere);
               y += 10; // increment height
            }
            scene.registerBeforeRender(function() {
               allspheres.forEach(function(obj) {
                  // if the sphers falls down its updated again over here
                  // if object falls
                  if (obj.position.y <-100) {
                     obj.position = getPosition(200);
                  }
               });
            })
            return scene;
         };
         var scene = createScene();
         engine.runRenderLoop(function() {
            scene.render();
         });
      </script>
   </body>
</html>

输出

上面的代码行生成以下输出-
物理引擎
在这个演示中,我们使用了图像 images/gr1.jpg。图片保存在本地的images/文件夹中,也贴在下面供参考。您可以下载任何您选择的图片并在演示链接中使用。

图片/gr1.jpg

GR1

说明

scene.enablePhysics(new BABYLON.Vector3(0,-10,0), new BABYLON.OimoJSPlugin());
以上行启用 Physics 插件。您可以使用您选择的插件。我们已经使用了 OimoJsplugin()。
g.physicsImpostor = newBABYLON.PhysicsImpostor(g, BABYLON.PhysicsImpostor.BoxImpostor, {
   mass: 0,
   restitution: 0.9
}, scene);
对于交互,物理引擎使用冒名顶替。当应用于 impostor 时,对象的形状不能改变。如果更改,则必须创建新的冒名顶替者。
对于球体,我们将设置冒名顶替者并为其添加脉冲以实现反弹效果,如图所示-
redSphere.physicsImpostor = new BABYLON.PhysicsImpostor(
   redSphere, BABYLON.PhysicsImpostor.SphereImpostor, {
      mass: 1,
      restitution:0.9
   }, scene
);
redSphere.physicsImpostor.applyImpulse(
   new BABYLON.Vector3(1, 2,-1),
   new BABYLON.Vector3(1, 2, 0)
);

physicsImposter 的参数

考虑以下物理效果参数-

对象

这里是您要应用交互的对象。例如球体、盒子等

类型

类型可以是以下之一-
BABYLON.PhysicsImpostor.SphereImpostor; BABYLON.PhysicsImpostor.BoxImpostor; BABYLON.PhysicsImpostor.PlaneImpostor; BABYLON.PhysicsImpostor.MeshImpostor; BABYLON.PhysicsImpostor.CylinderImpostor; BABYLON.PhysicsImpostor.ParticleImpostor; BABYLON.PhysicsImpostor.HeightmapImpostor;

质量

唯一的强制参数是质量,即物体的质量(公斤)。 0 作为值将创建一个静态冒名顶替者-对地板有益。

恢复原状

这是碰撞时身体将"返回"的力的大小。较低的值不会产生反弹,而值为 1 将是非常有弹性的交互。
scene.registerBeforeRender(function() {
   allspheres.forEach(function(obj) {
      // if the sphers falls down its updated again over here
      // if object falls
      if (obj.position.y <-100) {
         obj.position = getPosition(200);
      }
   });
})
以上代码将掉落的球体带回地面。它会不断更新任何掉落的球体的地面。在浏览器中尝试上面的演示以查看物理效果。
