BabylonJS 矢量

在浏览器中运行下面给出的演示链接。在下面给出的演示中，我们绘制了 x、y 和 z 轴。在 x、y 和 z 轴的正负方向上绘制了数字。在浏览器中运行相同的程序，根据需要更改值并绘制形状、网格、定位它们并查看它们如何在 x、y 和 z 轴上呈现。使用 x、y 和 z 轴上提到的数字，看看网格的定位是如何完成的会很有帮助。

演示

<!doctype html>
<html>
   <head>
      <meta charset = "utf-8">
      <title>BabylonJs-Basic Element-Creating Scene</title>
      <script src = "babylon.js"></script>
      <style>
         canvas {width: 100%; height: 100%;}
      </style>
   </head>
   <body>
      <canvas id = "renderCanvas"></canvas>
      <script type = "text/javascript">
         var canvas = document.getElementById("renderCanvas");
         var engine = new BABYLON.Engine(canvas, true);
         var createScene  = function() {
            var scene = new BABYLON.Scene(engine);
            scene.clearColor = new BABYLON.Color3( .5, .5, .5);
            // camera
            var camera = new BABYLON.ArcRotateCamera("camera1",  0, 0, 0, new BABYLON.Vector3(5, 3, 0), scene);
            camera.setPosition(new BABYLON.Vector3(5, 10,-10));
            camera.attachControl(canvas, true);

            // lights
            var light = new BABYLON.HemisphericLight("light1", new BABYLON.Vector3(1, 0.5, 0), scene);
            light.intensity = 0.8;
            var spot = new BABYLON.SpotLight(
               "spot",
               new BABYLON.Vector3(25, 15,-10),
               new BABYLON.Vector3(-1,-0.8, 1), 15, 1, scene);
            spot.diffuse = new BABYLON.Color3(1, 1, 1);
            spot.specular = new BABYLON.Color3(0, 0, 0);
            spot.intensity = 0.2;

            // material
            var mat = new BABYLON.StandardMaterial("mat1", scene);
            mat.alpha = 1.0;
            mat.diffuseColor = new BABYLON.Color3(0.5, 0.5, 1.0);
            mat.backFaceCulling = false;
            //mat.wireframe = true;
            // show axis
            var showAxis = function(size) {
               var makeTextPlane = function(text, color, size) {
                  var dynamicTexture = new BABYLON.DynamicTexture("DynamicTexture", 50, scene, true);
                  dynamicTexture.hasAlpha = true;
                  dynamicTexture.drawText(text, 5, 40, "bold 36px Arial", color , "transparent", true);

                  var plane = new BABYLON.Mesh.CreatePlane("TextPlane", size, scene, true);
                  plane.material = new BABYLON.StandardMaterial("TextPlaneMaterial", scene);
                  plane.material.backFaceCulling = false;

                  plane.material.specularColor = new BABYLON.Color3(0, 0, 0);
                  plane.material.diffuseTexture = dynamicTexture;
                  return plane;
               };
               var axisX = BABYLON.Mesh.CreateLines("axisX", [
                  new BABYLON.Vector3(-size * 0.95, 0.05 * size, 0),
                  new BABYLON.Vector3(-size, 0, 0),
                  new BABYLON.Vector3(-size * 0.95,-0.05 * size, 0),
                  new BABYLON.Vector3(-size, 0, 0),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(size, 0, 0),
                  new BABYLON.Vector3(size * 0.95, 0.05 * size, 0),
                  new BABYLON.Vector3(size, 0, 0),
                  new BABYLON.Vector3(size * 0.95,-0.05 * size, 0)
               ], scene);

               axisX.color = new BABYLON.Color3(1, 0, 0);
               var xChar = makeTextPlane("X", "red", size / 10);
               xChar.position = new BABYLON.Vector3(0.9 * size,-0.05 * size, 0);
               var xChar1 = makeTextPlane("-X", "red", size / 10);
               xChar1.position = new BABYLON.Vector3(-0.9 * size, 0.05 * size, 0);
               var axisY = BABYLON.Mesh.CreateLines("axisY", [
                  new BABYLON.Vector3(-0.05 * size,-size * 0.95, 0),
                  new BABYLON.Vector3(0,-size, 0),
                  new BABYLON.Vector3(0.05 * size,-size * 0.95, 0),
                  new BABYLON.Vector3(0,-size, 0),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(0, size, 0),
                  new BABYLON.Vector3(-0.05 * size, size * 0.95, 0),
                  new BABYLON.Vector3(0, size, 0),
                  new BABYLON.Vector3( 0.05 * size, size * 0.95, 0)
               ], scene);

               axisY.color = new BABYLON.Color3(0, 1, 0);
               var yChar = makeTextPlane("Y", "green", size / 10);
               yChar.position = new BABYLON.Vector3(0, 0.9 * size,-0.05 * size);
               var yChar1 = makeTextPlane("-Y", "green", size / 10);
               yChar1.position = new BABYLON.Vector3(0,-0.9 * size, 0.05 * size);
               var axisZ = BABYLON.Mesh.CreateLines("axisZ", [
                  new BABYLON.Vector3( 0 ,-0.05 * size,-size * 0.95),
                  new BABYLON.Vector3(0, 0,-size),
                  new BABYLON.Vector3( 0 , 0.05 * size,-size * 0.95),
                  new BABYLON.Vector3(0, 0,-size),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(0, 0, size),
                  new BABYLON.Vector3( 0 ,-0.05 * size, size * 0.95),
                  new BABYLON.Vector3(0, 0, size),
                  new BABYLON.Vector3( 0, 0.05 * size, size * 0.95)
               ], scene);

               axisZ.color = new BABYLON.Color3(0, 0, 1);
               var zChar = makeTextPlane("Z", "blue", size / 10);
               zChar.position = new BABYLON.Vector3(0, 0.05 * size, 0.9 * size);
               var zChar1 = makeTextPlane("-Z", "blue", size / 10);
               zChar1.position = new BABYLON.Vector3(0, 0.05 * size,-0.9 * size);
            };
            showAxis(10);
            return scene;
         };
         var scene = createScene();
         engine.runRenderLoop(function() {
            scene.render();
         });
      </script>
   </body>
</html>

输出

让我们沿 x、y 和 z 轴定义坐标。

演示

<!doctype html>
<html>
   <head>
      <meta charset = "utf-8">
      <title>BabylonJs-Basic Element-Creating Scene</title>
      <script src = "babylon.js"></script>
      <style>
         canvas {width: 100%; height: 100%;}
      </style>
   </head>
   <body>
      <canvas id = "renderCanvas"></canvas>
      <script type = "text/javascript">
         var canvas = document.getElementById("renderCanvas");
         var engine = new BABYLON.Engine(canvas, true);
         var createScene  = function() {
            var scene = new BABYLON.Scene(engine);
            scene.clearColor = new BABYLON.Color3( .5, .5, .5);
            // camera
            var camera = new BABYLON.ArcRotateCamera("camera1",  0, 0, 0, new BABYLON.Vector3(5, 3, 0), scene);
            camera.setPosition(new BABYLON.Vector3(5, 10,-10));
            camera.attachControl(canvas, true);

            // lights
            var light = new BABYLON.HemisphericLight("light1", new BABYLON.Vector3(1, 0.5, 0), scene);
            light.intensity = 0.8;
            var spot = new BABYLON.SpotLight(
               "spot", new BABYLON.Vector3(25, 15,-10),
               new BABYLON.Vector3(-1,-0.8, 1), 15, 1, scene);
            spot.diffuse = new BABYLON.Color3(1, 1, 1);
            spot.specular = new BABYLON.Color3(0, 0, 0);
            spot.intensity = 0.2;

            // material
            var mat = new BABYLON.StandardMaterial("mat1", scene);
            mat.alpha = 1.0;
            mat.diffuseColor = new BABYLON.Color3(0.5, 0.5, 1.0);
            mat.backFaceCulling = false;

            //mat.wireframe = true;
            var makeTextPlane = function(text, color, size) {
               var dynamicTexture = new BABYLON.DynamicTexture("DynamicTexture", 50, scene, true);
               dynamicTexture.hasAlpha = true;
               dynamicTexture.drawText(text, 5, 40, "bold 36px Arial", color , "transparent", true);

               var plane = new BABYLON.Mesh.CreatePlane("TextPlane", size, scene, true);
               plane.material = new BABYLON.StandardMaterial("TextPlaneMaterial", scene);
               plane.material.backFaceCulling = false;
               plane.material.specularColor = new BABYLON.Color3(0, 0, 0);
               plane.material.diffuseTexture = dynamicTexture;
               return plane;
            };

            // show axis
            var showAxis = function(size) {
               var axisX = BABYLON.Mesh.CreateLines("axisX", [
                  new BABYLON.Vector3(-size * 0.95, 0.05 * size, 0),
                  new BABYLON.Vector3(-size, 0, 0),
                  new BABYLON.Vector3(-size * 0.95,-0.05 * size, 0),
                  new BABYLON.Vector3(-size, 0, 0),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(size, 0, 0),
                  new BABYLON.Vector3(size * 0.95, 0.05 * size, 0),
                  new BABYLON.Vector3(size, 0, 0),
                  new BABYLON.Vector3(size * 0.95,-0.05 * size, 0)
               ], scene);
               axisX.color = new BABYLON.Color3(1, 0, 0);
               var xChar = makeTextPlane("X", "red", size / 10);
               xChar.position = new BABYLON.Vector3(0.9 * size,-0.05 * size, 0);
               var xChar1 = makeTextPlane("-X", "red", size / 10);
               xChar1.position = new BABYLON.Vector3(-0.9 * size, 0.05 * size, 0);
               var xcor = [];
               for (i =-10; i <= 10; i++) {
                  xcor[i] = makeTextPlane(i, "red", size / 10);
                  xcor[i].position = new BABYLON.Vector3(i, 0, 0);
               }
               var axisY = BABYLON.Mesh.CreateLines("axisY", [
                  new BABYLON.Vector3(-0.05 * size,-size * 0.95, 0),
                  new BABYLON.Vector3(0,-size, 0),
                  new BABYLON.Vector3(0.05 * size,-size * 0.95, 0),
                  new BABYLON.Vector3(0,-size, 0),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(0, size, 0),
                  new BABYLON.Vector3(-0.05 * size, size * 0.95, 0),
                  new BABYLON.Vector3(0, size, 0),
                  new BABYLON.Vector3( 0.05 * size, size * 0.95, 0)
               ], scene);

               axisY.color = new BABYLON.Color3(0, 1, 0);
               var yChar = makeTextPlane("Y", "green", size / 10);
               yChar.position = new BABYLON.Vector3(0, 0.9 * size,-0.05 * size);
               var yChar1 = makeTextPlane("-Y", "green", size / 10);
               yChar1.position = new BABYLON.Vector3(0,-0.9 * size, 0.05 * size);
               var ycor = [];
               for (y=-10;y<=10;y++) {
                  xcor[y] = makeTextPlane(y, "green", size / 10);
                  xcor[y].position = new BABYLON.Vector3(0, y, 0);
               }
               var axisZ = BABYLON.Mesh.CreateLines("axisZ", [
                  new BABYLON.Vector3( 0 ,-0.05 * size,-size * 0.95),
                  new BABYLON.Vector3(0, 0,-size),
                  new BABYLON.Vector3( 0 , 0.05 * size,-size * 0.95),
                  new BABYLON.Vector3(0, 0,-size),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(0, 0, size),
                  new BABYLON.Vector3( 0 ,-0.05 * size, size * 0.95),
                  new BABYLON.Vector3(0, 0, size),
                  new BABYLON.Vector3( 0, 0.05 * size, size * 0.95)
               ], scene);

               axisZ.color = new BABYLON.Color3(0, 0, 1);
               var zChar = makeTextPlane("Z", "blue", size / 10);
               zChar.position = new BABYLON.Vector3(0, 0.05 * size, 0.9 * size);
               var zChar1 = makeTextPlane("-Z", "blue", size / 10);
               zChar1.position = new BABYLON.Vector3(0, 0.05 * size,-0.9 * size);
               var zcor = [];
               for (z =-10; z <= 10; z++) {
                  xcor[z] = makeTextPlane(z, "green", size / 10);
                  xcor[z].position = new BABYLON.Vector3(0, 0, z);
               }
            };
            //Lets draw a mesh along the axis.
            var spriteManagerPlayer = new BABYLON.SpriteManager("playerManager", "images/bird.png", 1, 200, scene);
            var player = new BABYLON.Sprite("player", spriteManagerPlayer);
            player.position.x = 2;
            player.position.y = 2;
            player.position.z = 0;
            var zChardot = makeTextPlane(".", "red", 1);
            zChardot.position = new BABYLON.Vector3(1.8, 1.8,0);
            var box = BABYLON.Mesh.CreateBox("box", '2', scene);
            box.position = new BABYLON.Vector3(-5,3,0); // center point of box x-axis is-5 and y axis is 3.
            var box = BABYLON.Mesh.CreateBox("box", '2', scene);
            box.position = new BABYLON.Vector3(0,3,-3); // center point of box x-axis is-5 and y axis is 3.
            var redSphere = BABYLON.Mesh.CreateSphere("red", 32, 1, scene); //no position for sphere so by default it takes 0,0,0
            showAxis(10);
            returnscene;
         };
         var scene = createScene();
         engine.runRenderLoop(function() {
            scene.render();
         });
      </script>
   </body>
</html>

输出

上面的代码行生成以下输出-

在这个演示中，我们使用了 imagebird.png。图片保存在本地的images/文件夹中，也贴在下面供参考。您可以下载任何您选择的图片并在演示链接中使用。

图片/bird.png

演示

<!doctype html>
<html>
   <head>
      <meta charset = "utf-8">
      <title>BabylonJs-Basic Element-Creating Scene</title>
      <script src = "babylon.js"></script>
      <style>
         canvas {width: 100%; height: 100%;}
      </style>
   </head>
   <body>
      <canvas id = "renderCanvas"></canvas>
      <script type = "text/javascript">
         var canvas = document.getElementById("renderCanvas");
         var engine = new BABYLON.Engine(canvas, true);
         var createScene  = function() {
            var scene = new BABYLON.Scene(engine);
            scene.clearColor = new BABYLON.Color3( .5, .5, .5);
            // camera
            var camera = new BABYLON.ArcRotateCamera("camera1",  0, 0, 0, new BABYLON.Vector3(5, 3, 0), scene);
            camera.setPosition(new BABYLON.Vector3(5, 10,-10));
            camera.attachControl(canvas, true);

            // lights
            var light = new BABYLON.HemisphericLight("light1", new BABYLON.Vector3(1, 0.5, 0), scene);
            light.intensity = 0.8;

            var spot = new BABYLON.SpotLight(
               "spot",
               new BABYLON.Vector3(25, 15,-10),
               new BABYLON.Vector3(-1,-0.8, 1), 15, 1, scene);
            spot.diffuse = new BABYLON.Color3(1, 1, 1);
            spot.specular = new BABYLON.Color3(0, 0, 0);
            spot.intensity = 0.2;

            // material
            var mat = new BABYLON.StandardMaterial("mat1", scene);
            mat.alpha = 1.0;
            mat.diffuseColor = new BABYLON.Color3(0.5, 0.5, 1.0);
            mat.backFaceCulling = false;

            //mat.wireframe = true;
            var makeTextPlane = function(text, color, size) {
               var dynamicTexture = new BABYLON.DynamicTexture("DynamicTexture", 50, scene, true);
               dynamicTexture.hasAlpha = true;
               dynamicTexture.drawText(text, 5, 40, "bold 36px Arial", color , "transparent", true);
               var plane = new BABYLON.Mesh.CreatePlane("TextPlane", size, scene, true);
               plane.material = new BABYLON.StandardMaterial("TextPlaneMaterial", scene);
               plane.material.backFaceCulling = false;
               plane.material.specularColor = new BABYLON.Color3(0, 0, 0);
               plane.material.diffuseTexture = dynamicTexture;
               return plane;
            };

            // show axis
            var showAxis = function(size) {
               var axisX = BABYLON.Mesh.CreateLines("axisX", [
                  new BABYLON.Vector3(-size * 0.95, 0.05 * size, 0),
                  new BABYLON.Vector3(-size, 0, 0),
                  new BABYLON.Vector3(-size * 0.95,-0.05 * size, 0),
                  new BABYLON.Vector3(-size, 0, 0),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(size, 0, 0),
                  new BABYLON.Vector3(size * 0.95, 0.05 * size, 0),
                  new BABYLON.Vector3(size, 0, 0),
                  new BABYLON.Vector3(size * 0.95,-0.05 * size, 0)], scene);
               axisX.color = new BABYLON.Color3(1, 0, 0);
               var xChar = makeTextPlane("X", "red", size / 10);
               xChar.position = new BABYLON.Vector3(0.9 * size,-0.05 * size, 0);
               var xChar1 = makeTextPlane("-X", "red", size / 10);
               xChar1.position = new BABYLON.Vector3(-0.9 * size, 0.05 * size, 0);
               var xcor = [];
               for (i =-10; i <= 10; i++) {
                  xcor[i] = makeTextPlane(i, "red", size / 10);
                  xcor[i].position = new BABYLON.Vector3(i, 0, 0);
               }
               var axisY = BABYLON.Mesh.CreateLines("axisY", [
                  new BABYLON.Vector3(-0.05 * size,-size * 0.95, 0),
                  new BABYLON.Vector3(0,-size, 0),
                  new BABYLON.Vector3(0.05 * size,-size * 0.95, 0),
                  new BABYLON.Vector3(0,-size, 0),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(0, size, 0),
                  new BABYLON.Vector3(-0.05 * size, size * 0.95, 0),
                  new BABYLON.Vector3(0, size, 0),
                  new BABYLON.Vector3( 0.05 * size, size * 0.95, 0)
               ], scene);

               axisY.color = new BABYLON.Color3(0, 1, 0);
               var yChar = makeTextPlane("Y", "green", size / 10);
               yChar.position = new BABYLON.Vector3(0, 0.9 * size,-0.05 * size);
               var yChar1 = makeTextPlane("-Y", "green", size / 10);
               yChar1.position = new BABYLON.Vector3(0,-0.9 * size, 0.05 * size);
               var ycor = [];
               for (y =-10; y <= 10; y++) {
                  xcor[y] = makeTextPlane(y, "green", size / 10);
                  xcor[y].position = new BABYLON.Vector3(0, y, 0);
               }
               var axisZ = BABYLON.Mesh.CreateLines("axisZ", [
                  new BABYLON.Vector3( 0 ,-0.05 * size,-size * 0.95),
                  new BABYLON.Vector3(0, 0,-size),
                  new BABYLON.Vector3( 0 , 0.05 * size,-size * 0.95),
                  new BABYLON.Vector3(0, 0,-size),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(0, 0, size),
                  new BABYLON.Vector3( 0 ,-0.05 * size, size * 0.95),
                  new BABYLON.Vector3(0, 0, size),
                  new BABYLON.Vector3( 0, 0.05 * size, size * 0.95)
               ], scene);
               axisZ.color = new BABYLON.Color3(0, 0, 1);
               var zChar = makeTextPlane("Z", "blue", size / 10);
               zChar.position = new BABYLON.Vector3(0, 0.05 * size, 0.9 * size);
               var zChar1 = makeTextPlane("-Z", "blue", size / 10);
               zChar1.position = new BABYLON.Vector3(0, 0.05 * size,-0.9 * size);
               var zcor = [];
               for (z =-10; z <= 10; z++) {
                  xcor[z] = makeTextPlane(z, "green", size / 10);
                  xcor[z].position = new BABYLON.Vector3(0, 0, z);
               }
            };
            var kite = BABYLON.Mesh.CreateLines("kite", [
               new BABYLON.Vector3(-4,0,0),
               new BABYLON.Vector3(0,4,0),
               new BABYLON.Vector3(4,0,0),
               new BABYLON.Vector3(0,-4,0),
               new BABYLON.Vector3(-4,0,0)
            ], scene);
            kite.color = new BABYLON.Color3(1, 1, 1);
            var path = [];
            path.push(new BABYLON.Vector3(-4, 0, 0));
            path.push(new BABYLON.Vector3(0, 0, 0));
            path.push(new BABYLON.Vector3(4, 0, 0));
            var lines1 = BABYLON.Mesh.CreateLines("lines",path, scene, true);
            lines1.color = new BABYLON.Color3(1, 1, 1);
            showAxis(10);
            return scene;
         };
         var scene = createScene();
         engine.runRenderLoop(function() {
            scene.render();
         });
      </script>
   </body>
</html>

输出

上面的代码行将生成以下输出：

矢量旋转

现在让我们看看矢量旋转是如何工作的。

演示

<!doctype html>
<html>
   <head>
      <meta charset = "utf-8">
      <title>BabylonJs-Basic Element-Creating Scene</title>
      <script src = "babylon.js"></script>
      <style>
         canvas {width: 100%; height: 100%;}
      </style>
   </head>
   <body>
      <canvas id = "renderCanvas"></canvas>
      <script type = "text/javascript">
         var canvas = document.getElementById("renderCanvas");
         var engine = new BABYLON.Engine(canvas, true);
         var createScene  = function() {
            var scene = new BABYLON.Scene(engine);
            scene.clearColor = new BABYLON.Color3( .5, .5, .5);
            // camera
            var camera = new BABYLON.ArcRotateCamera("camera1",  0, 0, 0, new BABYLON.Vector3(5, 3, 0), scene);
            camera.setPosition(new BABYLON.Vector3(0, 0, 0));
            camera.attachControl(canvas, true);

            // lights
            var light = new BABYLON.HemisphericLight("light1", new BABYLON.Vector3(1, 0.5, 0), scene);
            light.intensity = 0.8;
            var spot = new BABYLON.SpotLight(
               "spot",
               new BABYLON.Vector3(25, 15,-10),
               new BABYLON.Vector3(-1,-0.8, 1), 15, 1, scene);
            spot.diffuse = new BABYLON.Color3(1, 1, 1);
            spot.specular = new BABYLON.Color3(0, 0, 0);
            spot.intensity = 0.2;

            // material
            var mat = new BABYLON.StandardMaterial("mat1", scene);
            mat.alpha = 1.0;
            mat.diffuseColor = new BABYLON.Color3(0.5, 0.5, 1.0);
            mat.backFaceCulling = false;

            //mat.wireframe = true;
            var makeTextPlane = function(text, color, size) {
               var dynamicTexture = new BABYLON.DynamicTexture("DynamicTexture", 50, scene, true);
               dynamicTexture.hasAlpha = true;
               dynamicTexture.drawText(text, 5, 40, "bold 36px Arial", color , "transparent", true);
               var plane = new BABYLON.Mesh.CreatePlane("TextPlane", size, scene, true);
               plane.material = new BABYLON.StandardMaterial("TextPlaneMaterial", scene);
               plane.material.backFaceCulling = false;
               plane.material.specularColor = new BABYLON.Color3(0, 0, 0);
               plane.material.diffuseTexture = dynamicTexture;
               return plane;
            };
            // show axis
            var showAxis = function(size) {
               var axisX = BABYLON.Mesh.CreateLines("axisX", [
                  new BABYLON.Vector3(-size * 0.95, 0.05 * size, 0),
                  new BABYLON.Vector3(-size, 0, 0),
                  new BABYLON.Vector3(-size * 0.95,-0.05 * size, 0),
                  new BABYLON.Vector3(-size, 0, 0),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(size, 0, 0),
                  new BABYLON.Vector3(size * 0.95, 0.05 * size, 0),
                  new BABYLON.Vector3(size, 0, 0),
                  new BABYLON.Vector3(size * 0.95,-0.05 * size, 0)
               ], scene);

               axisX.color = new BABYLON.Color3(1, 0, 0);
               var xChar = makeTextPlane("X", "red", size / 10);
               xChar.position = new BABYLON.Vector3(0.9 * size,-0.05 * size, 0);
               var xChar1 = makeTextPlane("-X", "red", size / 10);
               xChar1.position = new BABYLON.Vector3(-0.9 * size, 0.05 * size, 0);
               var xcor = [];
               for (i =-10; i <= 10; i++) {
                  xcor[i] = makeTextPlane(i, "red", size / 10);
                  xcor[i].position = new BABYLON.Vector3(i, 0, 0);
               }
               var axisY = BABYLON.Mesh.CreateLines("axisY", [
                  new BABYLON.Vector3(-0.05 * size,-size * 0.95, 0),
                  new BABYLON.Vector3(0,-size, 0),
                  new BABYLON.Vector3(0.05 * size,-size * 0.95, 0),
                  new BABYLON.Vector3(0,-size, 0),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(0, size, 0),
                  new BABYLON.Vector3(-0.05 * size, size * 0.95, 0),
                  new BABYLON.Vector3(0, size, 0),
                  new BABYLON.Vector3( 0.05 * size, size * 0.95, 0)
               ], scene);

               axisY.color = new BABYLON.Color3(0, 1, 0);
               var yChar = makeTextPlane("Y", "green", size / 10);
               yChar.position = new BABYLON.Vector3(0, 0.9 * size,-0.05 * size);
               var yChar1 = makeTextPlane("-Y", "green", size / 10);
               yChar1.position = new BABYLON.Vector3(0,-0.9 * size, 0.05 * size);
               var ycor = [];
               for (y =-10; y <= 10; y++) {
                  xcor[y] = makeTextPlane(y, "green", size / 10);
                  xcor[y].position = new BABYLON.Vector3(0, y, 0);
               }
               var axisZ = BABYLON.Mesh.CreateLines("axisZ", [
                  new BABYLON.Vector3( 0 ,-0.05 * size,-size * 0.95),
                  new BABYLON.Vector3(0, 0,-size),
                  new BABYLON.Vector3( 0 , 0.05 * size,-size * 0.95),
                  new BABYLON.Vector3(0, 0,-size),
                  new BABYLON.Vector3.Zero(),
                  new BABYLON.Vector3(0, 0, size),
                  new BABYLON.Vector3( 0 ,-0.05 * size, size * 0.95),
                  new BABYLON.Vector3(0, 0, size),
                  new BABYLON.Vector3( 0, 0.05 * size, size * 0.95)
               ], scene);

               axisZ.color = new BABYLON.Color3(0, 0, 1);
               var zChar = makeTextPlane("Z", "blue", size / 10);
               zChar.position = new BABYLON.Vector3(0, 0.05 * size, 0.9 * size);
               var zChar1 = makeTextPlane("-Z", "blue", size / 10);
               zChar1.position = new BABYLON.Vector3(0, 0.05 * size,-0.9 * size);
               var zcor = [];
               for (z =-10; z <= 10; z++) {
                  xcor[z] = makeTextPlane(z, "green", size / 10);
                  xcor[z].position = new BABYLON.Vector3(0, 0, z);
               }
            };
            var yellowSphere = BABYLON.Mesh.CreateSphere("yellowSphere",32, 1, scene);
            yellowSphere.setPivotMatrix(BABYLON.Matrix.Translation(2, 0, 0));
            var yellowMaterial = new BABYLON.StandardMaterial("yellowMaterial", scene);
            yellowMaterial.diffuseColor = BABYLON.Color3.Yellow();
            yellowSphere.material = yellowMaterial;
            var wheel1 = BABYLON.MeshBuilder.CreateTorus('t1', {diameter: 2.0}, scene);
            wheel1.position.x =-2.0
            wheel1.position.z =-2.0;
            showAxis(10);
            var k = 0.0;
            var y = 0.0;
            var x = 0.0;
            scene.registerBeforeRender(function () {
               wheel1.rotation.copyFromfloats(0.0, 0.0, Math.PI / 2);
               wheel1.addRotation(0.0, y, 0.0);
               wheel1.addRotation(x, 0.0, 0.0);
               yellowSphere.rotation.y += 0.01;
               y += 0.05;
            });
            return scene;
         };
         var scene = createScene();
         engine.runRenderLoop(function() {
            scene.render();
         });
      </script>
   </body>
</html>

输出

上面的代码行生成以下输出-

找工作要求35岁以下，35岁以上的程序员都干什么去了？

长久以来，一直有一个问题困扰着技术人——如何打破“程序员的35岁职业魔咒”，这一天迟早会到来，或早或晚。

或许是选错了行业，程序员薪水虽高，但光鲜的外表下，背后的苦衷只有自己知道。三十多岁本该是一个人事业的黄金期，但技术变化日新月异，行业竞争异常残酷，对一个企业来说，永远有比你更年轻、劳动成本更低的人可以选择，这让你的中年危机提前到来。破局的智慧可以看看这本书！>>

<< BabylonJS 网格 BabylonJS 贴花 >>

昵称：邮箱：
